UV Photodiodes
- active area from 0.06 mm² to 36 mm² and quadrant photodiodes for position detections
- spectral response for broadband UV or filtered for UVA, UVB, UVC or UV-Index
- various entrance optics and housings options available (TO or SMD)
- our own SiC photodiode chip production since 2009
- also available with VUV sensitivity
- PTB (German equivalent of NIST or NPL) measured high radiation hardness
- 350°C high temperature stable photodiodes available
- photodiode application guide
All photodiodes are always on stock, no minimum order quantity. They can be ordered via our web shop or with an email addressed to welcome@sglux.de. Alternatively, we are happy to issue a quotation or you may click on our shop’s QUOTATION function, instead of CHECKOUT.
-
Broadband UV (32)
spectral sensitivity from 221 to 358 nm, peak wavelength 280 nm, different packagings, sorted by detector areas. -
UVA (10)
spectral sensitivity from 309 to 367 nm, peak wavelength 331 nm, different packagings, sorted by detector areas. -
UVB+UVC (9)
spectral sensitivity from 231 to 309 nm, peak wavelength 280 nm, different packagings, sorted by detector areas. -
UVC (22)
spectral sensitivity from 225 to 287 nm, peak wavelength 275 nm, according to DVGW W 294-3:2006 and OENORM M5873 and DIN 19294, special version to control 275nm UVC LED available, different packagings, sorted by detector areas. -
UV-Index (Erythema) (2)
for UV-Index measurement according to ISO 17166, less than 5 % measurement uncertainty = most precise currently available detector, with cosine correction available. -
Broadband UV with VUV sensitivity (below 200 nm) (6)
spectral sensitivity from 170 to 355 nm, peak wavelength 280 nm, sorted by detector areas. -
Galliumphosphid (GaP) (1)
spectral sensitivity from 240 to 560 nm, peak wavelength 445 nm, for UV + VIS measurements. -
UV+IR - Combinations (1)
Double-chip photodiodes for simultaneous measurement of UV and IR
